Description
AUTEL VAG SFD Authorization 1 Time
Tip: This is One Time VAG SFD Authorization Service, no need for shipping. If you need one year, click AUTEL VAG SFD Authorization 1 Year.
What is SFD?
The control units protected by SFD include Engine Electronics, Central Electrics, Instrument Cluster, Gateway Electrics, Multimedia Unit, and more.
Autel VAG SFD Security Gateway Unlock Guide & Instruction
| Model | Module | Function/Token Valid Time | |
| Audi A3/S3/RS3 (2020-on) Audi A6/S6/RS6 (2018-on) Audi A7/S7/RS7 (2018-on) Audi A7L (2022-on) Audi Q4 e-tron (2022-on) Audi Q5 e-tron (2022-on) Audi Q8/SQ8 (2019-on) Audi e-tron (2019-on) Audi e-tron GT (2021-on) Audi Q8 e-tron GT (2024-on) |
Volkswagen: A1/AC – T-Roc 2018 > AE/AW – Polo 2017 > AW/C1 – T-Cross 2019 > CK – Polo 2020 > CS – Taigo 2022 > CW – Taigun 2022 > D2 – Virtus 2022 > BF – T-Cross 2019 > BZ – Polo/Virtus 2018 > CH – Nivus 2020 > CY – Polo SUV 2022 > R1 – Polo Track 2023 > 5G/BA/BC/BE/BQ/BV/BX – Golf 2013 > 5T – Touran 2016 > AD/AX/BJ/BT – Tiguan 2016 > AM/AN – Golf Sports van 2014 > AU/BE/BX – Golf 2013 USA/CAN > BU – Jetta 2018 USA/CAN> BW – Tiguan 2018 USA/CAN> CL – Taos 2021 USA/CAN > CL/CQ – Taos 2021 > CP – Tarek 2021 > CD/CG – Golf 2020 > CD/CG – Golf 2022 USA/CAN > CK – Atlas PA 2024 USA/CAN > E1 – ID.3 2020 > E2/E3 ID.4 2021 > E2/E3 ID.5 2022 > E8 – ID.4 2021 USA/CAN > E6 – ID.4 Crozz 2021 > E7 – ID.6 Crozz 2021 > E4 – ID.4 X 2021 > E5 – ID.6 X 2021 > E9 – ID.3 2021 > EA – ID.7 Vizzion 2023 > ED – ID.7 Aero B 2023 > EB – ID.Buzz 2022 > CT – Tiguan 2024 > CT – Tiguan 2024 > CJ – Passat 2024 > |
Engine Control Unit Electronic Brake System Central Electrical System Airbags Instrument Cluster Data Bus Diagnostic Interface Brake Booster Multifunction Module Information Electronics System Communication Unit’s Emergency Call Module …. |
Function: To perform special functions, matching, coding, and other operations, you need to unlock the system first. Otherwise, the ECU will deny access. This applies to tasks like maintenance resets, brake pad replacements, airbag module coding, etc.
Token Valid time: Normally, once unlock the modules, it will be operated for a duration of up 90 minutes. The ECU will automatically lock itself, and need to unlock again |
| Volkswagen CV: SB – Caddy 2020 > ST – Multivan 2021> EB – ID.Buzz 2023 > |
|||
| Seat: KL – Leon 2020 > KM – Formentor 2021 > K1 – Born 2022 > |
|||
| Bentley: Bentayga 2017> Bentayga 2024> Flying Spur 2020> Continental Series 2018> |
|||
| Lamborghini: Revuelto 2024> |
|||
| Skoda: Scala 2019> Kamiq 2020> Slavia 2022 > Octavia 2020 > Enyaq 2021 > |
|||
SFD Unlocking Process
Two Factor Authentication:
Volkswagen requires two-factor authentication, please install the Google Authenticator app on your phone before proceeding. After the Google Authenticator app has been successfully installed, follow the instructions to bind it to your Autel account.
6. After the Autel account is successfully bound, a 6-digit dynamic authentication code will be displayed on your phone. Please press Authenticate on the diagnostic device and enter the latest authentication code to unlock the SFD.
For successfully finish the two-factor authentication, make sure the email you used on AUTEL ID can receive emails, if not, please [Switch Account]
Unlock Method & Support Device
| Unlock Method | 24H token for one VIN 1-year token subscription |
| Support Devices | MaxiSys Ultra series, Upcoming: MaxiSys 906 series, MaxiSys 908 series, MaxiDAS DS800 series, MaxiDAS DS900 series MaxiCheck MX808 series, MaxiCheck MX900 series |
How to Renew SFD Subscription?
If Volkswagen Auto Group Security Gateway function has been purchased before, then customer can go to OEM Authorization App to renew the subscription.
FAQs
